Ball Mill Gear Box Lubrication

CIRCOR Pumps and Systems in Power Generation Applications

Coal plants use a mill machine to finely pulverize coal before burning. These mills use large speed reducers between the motor drive and the mill and pumped or forced oil lubrication systems lubricate this equipment. Lubrication pump(s) may be driven from the reduction gear box or separately driven using electric motors.

Three screw pumps are commonly used to provide lubrication oil in ball mill gear box applications. The primary benefit that the 3-screw pump delivers in this application is its high resistance to contaminated fluids‚ as the highly abrasive fine pulverized coal will migrate into the gears and the lube oil reservoir.





Flow Rates up to Pressures to up to Max Fluid Temperature CIRCOR Brand‚ Series & Pump Type
2.7 m^3 / h
12 GPM
7 bar
101 psi
90C
194F
IMO AB ACD
Three Screw
11 m^3/h
48 GPM
16 bar
232 psi
155C
311F
IMO AB ACE
Three Screw
48 m^3/h
210 GPM
17 bar
250 psi
107C
233 F
IMO 3G
Three Screw
51 m^3/h
225 GPM
16 bar
232 psi
180C
356F
IMO AB ACG
Three Screw
91 m^3/h
400 GPM
35 bar
508 psi
121C
250F
IMO AB ACF
Three Screw
450 m^3/h
1982 GPM
16 bar
232 psi
90C
194 F
IMO AB LCQ
Three Screw
